Sam Sidecar Sam Model SI/S/005

Specification -Heavy-Duty Motorcycle Sidecar

SINGLE SEATER CHASSIS:-
Platform TYPE MILD STEEL PIPE ( OD 34MM X 26MM THICK ) For extra strength and vibration
free.
ATTACH MENT TO MOTORCYCLE: –
Fabricated Steel Adopters bolts / Adjustable Rod bolt/ U Clamps on the support bar that
connects the sidecar to the seat mount for lean in and out.
SUSPENSION: –
Independent wheel suspension with shock absorbers and trailing link unit having double ball
bearing hub.
Wheel and Tyre:-
Interchangeable Pressed Steel wheel Rims with spokes ( 3.25 X 19 inch )
we also have option for tyre sizes :-
3.50 X 19 inch / 18 inch/ 17 inch/ 16 inch
BODY:-
Made from Imported CRC 20SWG, metal Body painted to match vehicle color. Body is
connected to platform with LEATHER dampers to reduce vibration while driving entering the
body of sidecar plus independent wheel suspension with shock absorbers to reduce wobbling
during ride and smoothness in bumpy roads.

SEAT: –
Fully Upholstered rear seat Bucket type for extra comfort with lock and base, quickly
removable for cleaning.
LUGGAGE COMPARTMENT: –
More spacey and lockable rear compartment for extra safety .DOWNWARD OPENING.
Behind the SEAT.
LUGGAGE RACK :-
Chromed Luggage rack is provided with the sidecar as Accessories.
TRIMS : ALUMINUM PLANE STRIPS ROUND THE CURVATURE.
MUDGUARD and Lighting: –
Mudguard in Sheet metal matched with body and Curvature shape with backlight and rear
reflector for safety and extra view. Side indicator is provided.
FRONT BUMPER: –
STAINLESS STEEL front Bumper is provided for extra safety.
WEATHER PROTECTION: –
Bottom of the sidecar is painted with waterproof paints to increase life and to provide rust
proof environment. Sidecar includes TANQUE COVER – which covers sidecar at the time of
rainy season to avoid collection of water inside body.

DIMENSIONS: –
Length: – 6ft
WIDTH :- 60inch ( Includes Motorcycle)
45inch ( includes mudguard only not Motorcycle )
Height :- 36inch
Space :- 19 inch from body corner to corner.
Weight :- 60 KG (Complete)
Ground Clearance :- 12 inch

You can Attached our all Sam Sidecar models with any tubular bikes with our universal mounting kit which can allow our sidecar to any tubular bikes.
